Uniden XTRAK 80 Pro Smart UHF CB Radio + AT970BK 6.6 dBi Antenna Combo
Part number: XTRAK80-PRO_AT970
DETAILS
Uniden UHF CB radio packs
Smart UHF CB with a 6.6 dBi antenna
The XTRAK 80 Pro in-vehicle UHF CB with an AT970BK 1200mm fibreglass antenna. Bluetooth location sharing, an OLED display on the mic and a high gain antenna for open country.
The XTRAK 80 Pro pairs with the free XTRAK Pro App to share location, manage settings and find repeaters. The AT970BK is a 6.6 dBi ground independent antenna with a stainless steel spring and 4.5m of coax, made for trucks and 4WDs. Add an XTRAK 50 Pro handheld to share location on foot.
Bluetooth app
See where the rest of the group is
Pair your phone with the free XTRAK Pro App and the radio shares your location with other XTRAK Pro radios, including the XTRAK 50 Pro handheld, even without mobile phone service. The radios need to be within UHF CB range of each other. The app also lets you change radio settings, manage Selcall contacts and extra receive channels, find repeaters and send short text messages.
- ✓Location sharing without phone service
- ✓Repeater Find and text messages
- ✓Radio software updates by app
In the cab
The whole radio sits in your hand
The XTRAK 80 Pro puts the screen and controls on the remote speaker mic, so the compact base unit can hide under a seat or behind the dash. The large anti-glare OLED display has a dimmer for night driving, and the 2W speaker in the mic keeps voices clear over road noise.
- ✓Anti-glare OLED display with dimmer
- ✓2W speaker in the mic
- ✓Base unit only 24.8mm high
Antenna included
AT970BK 6.6 dBi fibreglass antenna
The AT970BK is a 1200mm fibreglass raydome antenna with 6.6 dBi gain, made for all-round use on flat terrain, in town and in the country. A heavy duty barrel style stainless steel spring takes the knocks off road, and it suits trucks and 4WDs. It's ground independent and comes with 4.5m of low loss coax and an FME connector with PL259 adaptor.
- ✓6.6 dBi gain, 1200mm long
- ✓Heavy duty stainless steel spring
- ✓4.5m coax with PL259 adaptor
Fitting
Magnetic mic mount, no hook
The magnetic mic mount sticks to the dash with its adhesive pad, and the mic snaps onto it without fiddling with a hanger hook. The base unit fits with the quick release bracket or the gimbal bracket, and the 2m extension cable lets you put it where it suits. It runs on 12V or 24V, so it suits cars, 4WDs and trucks.
- ✓Magnetic mic mount in the box
- ✓Quick release and gimbal brackets
- ✓12V or 24V power
Instant Replay
Missed a call? Play it back
The radio records what it receives, in normal channel mode and while scanning. Press the red REPLAY key to hear the last message again, and skip back through up to 6 minutes of recent transmissions. Three Smart Keys give one-touch access to instant channels, Triple Watch, squelch, call tone, monitor or the equaliser.
- ✓Up to 6 minutes of replay
- ✓Records while scanning
- ✓3 programmable Smart Keys
Goes well with
Complete your setup
Handheld that shares location with the XTRAK 80 Pro through the XTRAK Pro App.
Heavy duty folding bracket to mount your UHF antenna on the vehicle.
Frequently asked questions
Do I need a ground plane for the antenna?
No. The AT970BK is ground independent, so it suits a bull bar or bracket mount. It comes with 4.5m of low loss coax and an FME connector with PL259 adaptor.
What's the difference between the XTRAK 80 and XTRAK 80 Pro?
They share the same radio features. The Pro adds Bluetooth: the XTRAK Pro App for location sharing, settings and text messages, and Bluetooth audio to compatible headsets and vehicle speakers.
What phone do I need for the app?
An iOS or Android smartphone with Bluetooth 4.0 and GPS. The XTRAK Pro App is a free download. Software updates and offline maps download through your phone, so Uniden suggests using WiFi as the files can be large.
Do I need a licence to use it?
UHF CB in Australia is covered by the ACMA Citizen Band Radio Stations Class Licence, and you must follow the conditions in that licence. Uniden notes the radio must only be used in the country of purchase.
Can I talk on all 80 channels?
Most of them. Channels 22 and 23 are for data only, so voice transmission is blocked, and channels 61, 62 and 63 are reserved for future use and are receive only. Channels 5 and 35 are emergency channels.
Features
- ✓XTRAK 80 Pro in-vehicle UHF CB, 80 channels, 5W
- ✓AT970BK 6.6 dBi fibreglass antenna, 1200mm
- ✓Large anti-glare OLED display with dimmer on the mic
- ✓Instant Replay of up to 6 minutes of received calls
- ✓XTRAK Pro App for location sharing, settings and Repeater Find
- ✓Bluetooth audio to compatible headsets and vehicle speakers
- ✓Magnetic mic mount, 12V or 24V power
Specifications
| Channels | 80 UHF CB, narrowband |
| Channel notes | CH 22 and 23 data only (voice TX inhibited); CH 61 to 63 reserved, receive only |
| Transmit power | 5W maximum |
| Display | Anti-glare OLED with dimmer |
| Speaker | 2W in the remote speaker microphone |
| Instant Replay | Up to 6 minutes of received transmissions |
| Smart keys | 3 programmable |
| Scan | Open and Group Scan with Priority Channel Watch, Triple Watch, Master Scan |
| Squelch | 10 level |
| Quiet codes | 50 CTCSS and 104 DCS |
| Extra receive channels | 100 user programmable, 400 to 520MHz in 12.5kHz steps |
| Selcall | Yes, with Alpha Tag |
| Voice scramble | Yes |
| External speaker jack | Yes |
| Power | 12V or 24V DC (10.2V to 28.8V) |
| Mic extension cable | 2m |
| Base unit size | 126.5mm W x 99.8mm D x 24.8mm H |
| Bluetooth app | XTRAK Pro App for iOS and Android (phone needs Bluetooth 4.0 and GPS) |
| Bluetooth audio | Connects to compatible Bluetooth 5.0 headsets and vehicle speakers |
| Antenna | AT970BK fibreglass raydome, black |
| Antenna gain | 6.6 dBi, ground independent |
| Antenna length | 1200mm |
| Antenna spring | Heavy duty barrel style stainless steel |
| Antenna cable | 4.5m low loss coax, FME female with PL259 adaptor |
| Designed in | Japan |
| Warranty | 5 years radio, 1 year included accessories |
| Brand | Uniden |
What's Included
- 1 x XTRAK 80 Pro base unit
- 1 x XTRAK 80 Pro remote speaker microphone
- 1 x quick release bracket kit
- 1 x gimbal mounting bracket
- 1 x magnetic mic mount
- 1 x 2m mic extension cable
- 1 x DC power lead with fuse
- 1 x AT970BK 6.6 dBi antenna, 1200mm, with 4.5m coax and PL259 adaptor
Product Details
| SKU | XTRAK80-PRO_AT970 |
| Barcode # | 9322402015538 |
| Brand | Uniden |
| Shipping Weight | 1.4000kg |
| Shipping Width | 0.170m |
| Shipping Height | 0.100m |
| Shipping Length | 0.240m |
| Shipping Cubic | 0.004080000m3 |
